Suzuki Late Titanium Front Disc Bolt M8 (1.25mm) x 22mm Black

Titanium front disc bolt, hot forged from Grade 5 titanium (Ti-6Al-4V) with a tensile strength of 900–1050 MPa. CNC machined with rolled threads for precision and reliability. Sold individually.

Specifications

• Size: M8 x 22mm (1.25mm pitch)
• Material: Grade 5 Titanium (Ti-6Al-4V)
• Weight: 7g per bolt
• Finish: Black
• Forged head, CNC machined with rolled threads

Compatible Models

• Suzuki GSX-R1000 K5-K6 05-06
• Suzuki GSX-R1000 K7-K8 07-08
• Suzuki GSX-R1000 K9-L1 09-11
• Suzuki GSX-R1000 L2-L6 11-16
• Suzuki GSX-R600 K6-K7 06-07
• Suzuki GSX-R600 K8-L0 08-10
• Suzuki GSX-R750 K6-K7 06-07
• Suzuki GSX-R750 K8-L0 08-10
• Suzuki GSX-R750 L1+ 11>
• Suzuki GSX-R600 L1+ 11-16
• Suzuki DL650A V-Strom 2011
• Suzuki DL1000 V-Strom 02-09
• Suzuki DL650 V-Strom 08-09
• Suzuki GSF1200 Bandit 06
• Suzuki GSF1250 Bandit 07-09
• Suzuki GSF650 Bandit 05-06
• Suzuki GSF650SA Bandit 07-08
• Suzuki GSF650SA Bandit 09-10
• Suzuki GSR600 06-10
• Suzuki GSR750 11>
• Suzuki GSX1300BK B-King 07-12
• Suzuki SFV650 Gladius 09>
• Suzuki SV650 03-04
• Suzuki SV650 04-08
• Suzuki VZ800 Intruder M800Z 08>
• Suzuki GSX1300R Hayabusa 08-11

Important: Always verify the thread pitch, bolt length and diameter match your original manufacturer's bolt before fitting. Use original manufacturer torque values. Installation by a qualified technician is recommended.
