M8 (1.25mm) x 22mm Titanium Torx Head Bolt
Material : titanium Gr5 (Ti-6Al-4V)
Tensile Strength: 900~1050Mpa
Weight : 7g per bolt
Hot forged CNC machined with rolled threads
Finish : PVD Black
Head diameter : 16mm
Head depth : 3mm
Shoulder diameter : 10mm
Allen key size : 6mm
Excellent corrosion resistance
Install the bolts using the torque values specified by the original manufacturer. Always consult a qualified technicial or equivalent expert for installation. Make sure the thread pitch, bolt length, dimensions and diameter matches that of the original manufacturers bolt you intend to replace.
Compatibility includes the following models :
- Suzuki GSX-R1000 K5-K6 05-06
- Suzuki GSX-R1000 K7-K8 07-08
- Suzuki GSX-R1000 K9-L1 09-11
- Suzuki GSX-R1000 L2-L6 11-16
- Suzuki GSX-R600 K6-K7 06-07
- Suzuki GSX-R600 K8-L0 08-10
- Suzuki GSX-R750 K6-K7 06-07
- Suzuki GSX-R750 K8-L0 08-10
- Suzuki GSX-R750 L1+ 11>
- Suzuki GSX-R600 L1+ 11-16
- Suzuki DL650A V-Strom 2011
- Suzuki DL1000 V-Strom 02-09
- Suzuki DL650 V-Strom 08-09
- Suzuki GSF1200 Bandit 06
- Suzuki GSF1250 Bandit 07-09
- Suzuki GSF650 Bandit 05-06
- Suzuki GSF650SA Bandit 07-08
- Suzuki GSF650SA Bandit 09-10
- Suzuki GSR600 06-10
- Suzuki GSR750 11>
- Suzuki GSX1300BK B-King 07-12
- Suzuki SFV650 Gladius 09>
- Suzuki SV650 03-04
- Suzuki SV650 04-08
- Suzuki VZ800 Intruder M800Z 08>
- Suzuki GSX1300R Hayabusa 08-11
